TUNBRIDGE™
Single Handle Kitchen Faucet
Model:P188400LF
Product Features & Benefits
- Single lever control for ease of operation with one hand
- Spout swivels 360 degrees for added convenience
- Matching side sprayer for easy pot filling and clean-up around the sink
- 3-hole sink application
- With Side Sprayer
- ADA Compliant
Product Details
- Handle(s): Single Handle Lever
- With Side Sprayer: Yes
- Flow Rate: 1.80 gpm @ 60 psi, 6.8 L/min @ 414 kPa
- Valve Type: Washerless ball valve
- Installation: 3-hole 8" installation
- Spout Length: 9
- Spout Total Height: 8-5/8
- Spout Height Deck to Aerator: 6-1/4
Support, Repair Parts & Technical Specs
Maintenance & Installation Sheet
Technical Specifications
Parts & Accessories Diagram
Holes for Installation
3-hole 8" installation
Rated 2 out of
5
by
ryan101 from
Faucet flange for sprayer hose is garbage
The sprayer flange on the faucet looks like chrome but is actually plastic. It broke after a year of usage. This part need to be more robust ad it is also necessary to help hold the faucet down on the sink. The other problem is finding replacement parts. There are none at the store where the faucet is sold. I will not but this type again.
Date published: 2017-05-31
Where can I find a dishwasher snap fitting for this faucet?
I recently purchased this product and have had no luck finding a snap fitting for attaching my dishwater. I've looked at Canadian Tire, Rona, The Home Depot, Home Hardware and Walmart. Do you make one or know of any where in the Niagara Region or online I can purchase one that fits this faucet? Thank you.
Hi MD1, Thank you for your question. The model P188400LF is not recommended for use with a portable dishwasher. The portable dishwasher can cause potential leaks around the base of the spout. We do not offer portable dishwasher aerators.
Thanks,
Dave
Date published: 2015-01-21
Does this faucet have a temperature limit? The water does not get very hot.
Peerless single handle kitchen faucet
Hi Jim, Thank you for your question the model P188400LF does not have a temperature limit. There may be debris in the hot water supply affecting the flow of water. You will want to flush the faucet. I have attached a link to a how to flush your kitchen faucet video below. Don't forget to check the flow out of the supplpy line leading to the faucet and the stop as well.
Thanks,
Dave
http://www.deltafaucet.com/tools-resources/research/video-gallery/video.html?v=eWw-FdAezZY&cat=
Date published: 2014-05-05
