CLAYMORE™
Two Handle Bathroom Faucet
Model:P299685LF-OB
Product Features & Benefits
- WaterSense certification promotes water conservation
- Includes matching finish drain assembly
- Meets standards set by Americans with Disabilities Act (ADA)
- 3-hole 4 in. installation
- Water Efficient Product meeting CALGreen standards
- Low Lead Certified
- WaterSense Labeled
- ADA Compliant
Product Details
- Handle(s): Two Handle Lever
- Flow Rate: 1.20 gpm @ 60 psi, 4.5 L/min @ 414 kPa
- Valve Type: Washerless stem cartridge
- Installation: 3-hole 4" installation
- Spout Length: 5
- Spout Total Height: 7-1/2
- Spout Height Deck to Aerator: 4-5/16
Support, Repair Parts & Technical Specs
Maintenance & Installation Sheet
Technical Specifications
Parts & Accessories Diagram
Holes for Installation
3-hole 4" installation
Rated 4 out of
5
by
Charlie from
P299685LF-BN Bathroom Faucet
Excellent except for one thing. The rod that operates the drain had to be bent in order to get it to go through the vanity holes. Appears from my prior faucet that the drain rod hole in faucet is set back to far and does not allow a smooth movement of the drain rod. I rarely use the drain close, so not a big deal...
Date published: 2017-03-15
Rated 2 out of
5
by
swhit from
We liked the look....
We liked the look of the faucet and bought 4 from Walmart to go in our 3 bathrooms. The first one we installed worked great, but we waited to change out the other faucets until after new counters were installed. Went to install the others and ALL 3 leaked from INSIDE the faucet. I thought that we had gotten a great deal on these and turned out we got what we paid for.... trash. Now I have to go return the useless ones. I only gave it 2 stars, because when it isn't a defective one it does work and look nicely.
Date published: 2017-03-06
Rated 1 out of
5
by
LJ from
Does not work with a standard 3 hole sink
I did not read the reviews before I purchased this at Walmart, but like the other reviewer, after tons of work installing it on a one-piece pedastal sink, the stopper does not line up with the hole! Peerless says it is not a defect, I'm just hoping Walmart will let me return it after I have to tear it apart again. I think they should at least put a warning that it might not fit a standard 3-hole sink!
Date published: 2016-04-11
Rated 4 out of
5
by
1DisillusionedCustomer from
We unexpectedly find ourselves unable to install the new faucet, even though we like it and because of its design.
We purchased the Model # P299685LF-RB-W. After removing the original faucet on our American Standard sink and I was preparing to install the new one, only then did the problem become apparent. Why? There wasn't anything on the box the new faucet came in or the installation instructions sheet to alert me to the fact that the new, lift rod wasn't going to go through the existing, middle hole in the sink where the old one had. Now I don't know if I should chance drilling a small hole in the sink for the new, lift rod to go through or try to grind the middle, sink hole back far enough using the new, plastic gasket as a guide.
Date published: 2013-12-06
Rated 5 out of
5
by
Nikki89 from
GREAT product!!!!
This is my second bath fixture ( I am DIY renovating my two guest bathrooms) and by far, PEERLESS is a great product. It's stylish and affordable ( Walmart for the savings). It's been two weeks since the self installation and so far, no leaks.
Date published: 2013-08-12
Rated 5 out of
5
by
HappyCustomer from
remodel project... really happy!!
OMG...I'm a bull in the china shop kind of guy. this product was easy to install. The instructions are very easy to follow. Great comical instructions inside as well. I would definitely buy this product again.
Date published: 2012-12-13
Can you mount a Brita Faucet Filtration system on this without any special adapters. I understand the aerator end and the aerator would have to be removed. What size and thread is on this part?
Hello JDW1,
Thank you for your inquiry! We do not recommend attaching filters to this lavatory faucet. However, the spout and aerator of the Peerless Lavatory P299865LF-OB faucet is M21.5x1 female 55/64-27 male thread size.
Best regards,
Tanya
Date published: 2018-03-26
Does this faucet have a swivel spout?
Thank you for your inquiry, Dani! Unfortunately, the spout of the Peerless Lavatory P299685:F faucet is a fixed spout, it does not swivel/rotate.
https://media.peerlessfaucet.com/SpecSheet/PSP-L-P299685LF%20Rev%20C.pdf
Best regards,
Tanya
Date published: 2018-02-27
does this come with the drain assembly
Mom,
Thank you for your question. The pop-up drain assembly is included.
Best regards,
Jon
Date published: 2017-11-22
Supply lines
What size supply lines do you use with this product
None,
Thank you for your question. This faucet has 1/2" supply connections.
Best regards,
Jon
Date published: 2017-11-09
Does the spout swivel? Like on the 10 year old P99685 I have.
Hi richdag,
Thanks for your question. The spout does swivel side to side.
Best regards,
Jon
Date published: 2017-03-04
Installation
Can this be installed without its base?
Hi mgz, Thank you for your question. The model P299685LF cannot be installed without the faucet base.
Thanks,
Dave
Date published: 2015-04-16
How do I take apart the neck of the faucet to change part number RP41700?
Regarding the two handle lavatory faucet. The faucet leaks between the neck and the middle part of the base.
Hi Alain, Thank you for your question. To remove the spout on the model P299685LF and access the RP41700 bushings and o-rings you will need to unscrew the bonnet located at the base of the spout. Once this piece is detached from the valve body you can pull the spout up and out of the valve body.
Thanks,
Dave
Date published: 2014-09-22
cross taps are they available? I saw some at Canadian tire
I like the two handle lavatory faucet P29968LF
The number at Canadian Tire is 063-3576-2/902
Old stone house and we really like the old fashioned cross top tap.
If you still have them, do you have them in widespread too?
Hi Lo, Thank you for your question. We do not offer the model P299685 with cross handles. You can order either the H26 metal cross handles or H27 porcelain cross handles(see links below) separately and switch them out. The closest wide spread to this model is the P299196LF.
Thanks,
Dave
http://www.deltafaucet.com/repairparts/details/h26.html
http://www.deltafaucet.com/repairparts/details/h27.html
Date published: 2014-06-30
